Description
Galvanised Triple Grip – G300 / Z275
Triple grips are heavy-duty connectors designed for secure joining of timber members such as roof trusses, rafters and wall plates. Their compact, multi-leg configuration provides excellent load transfer in multiple directions, making them suitable for roof-to-wall, wall-to-floor, or ceiling connections.
Applications
- Roof truss to wall plate connections
- Rafters and studs to bottom plates
- Jack flyovers to truss
- AS 1684 compliant
Material
- G300 Structural Steel
Finish
- Galvanised Z275 for corrosion resistance
Dimensions
| Part | Orientation | Width (W) | Depth (D) | Leg Depth (L) | Height (H) | Thickness |
|---|---|---|---|---|---|---|
| HGTMRG | Right Hand | 38 mm | 41 mm | 74 mm | 113 mm | 1.0 mm |
| HGTMLG | Left Hand | 38 mm | 41 mm | 74 mm | 113 mm | 1.0 mm |
Installation Guide
Use minimum 30 × Ø2.8mm Hot Dip Galvanised Nails to achieve stated design capacities.
- Install at least 10 nails per connector:
- 4 nails into Face A
- 4 nails into Face B
- 2 nails into Face C
- Install at least 10 nails per connector:
