Description
HDG Clevis Hanger (Hot Dip Galvanised)
The HDG Clevis Hanger is a heavy-duty suspension fitting designed for securely supporting threaded rod, pipework, and mechanical services in structural and industrial applications.
Manufactured from mild steel and finished in hot dip galvanised (HDG) coating, these clevis hangers provide excellent corrosion resistance, making them suitable for both indoor and outdoor environments.
Available in multiple sizes, they offer a reliable and strong connection point for a wide range of suspension systems.
🔧 Applications
- Pipe and conduit suspension
- HVAC ducting systems
- Mechanical and plumbing installations
- Threaded rod support systems
- Structural and industrial suspension
⭐ Features & Benefits
- Hot dip galvanised for superior corrosion resistance
- Heavy-duty steel construction
- Designed for threaded rod suspension
- Strong and reliable load support
- Suitable for indoor & outdoor use
- Multiple sizes available for flexibility
- Easy installation
📏 AVAILABLE SIZES
M10 | M12 | M16
📊 TECHNICAL SPECIFICATIONS
| Property | Specification |
|---|---|
| Product Type | Clevis Hanger |
| Material | Mild Steel |
| Finish | Hot Dip Galvanised (HDG) |
| Specification | HEC |
| Sizes | M10, M12, M16 |
| Application | Suspension systems |
📐 DIMENSIONS
M10
- D: 11mm
- H: 85mm
- A: 70mm
- W: 25mm
- T: 5mm
- B: 15mm
- L: 35mm
M12
- D: 14mm
- H: 90mm
- A: 75mm
- W: 40mm
- T: 6mm
- B: 20mm
- L: 50mm
M16
- D: 18mm
- H: 95mm
- A: 75mm
- W: 50mm
- T: 6mm
- B: 20mm
- L: 50mm
M10 Light Duty
- D: 11mm
- H: 83mm
- A: 70mm
- W: 25mm
- T: 3mm
- B: 15mm
- L: 35mm
📦 PRODUCT DATA
| Size | Part Number | QFind |
|---|---|---|
| M10 | PHSMSGHCD-10 | H153-M10 |
| M12 | PHSMSGHCD-12 | H153-M12 |
| M16 | PHSMSGHCD-16 | H153-M16 |
| M10 LD | PHSMSZHCL-10 | H153-M10LD |
